Description
Sur-ron Light bee X
จักรยานไฟฟ้า • Electric Bike / E-Bike
Looking for a powerful and durable electric motorcycle that is great for both road and off-road use?
The SUR-RON’s Light Bee X street-legal version is now available to turn your most adventurous electric motorcycle driving fantasies into reality.
Specs / คุณสมบัติ
Top Speed (ความเร็วสูงสุด) : 75-80 km/h
Range (ระยะทางต่อชาร์จ) : 100 km
Weight (น้ำหนักตัวรถ) : 46 kg (with battery)
เบรกและช่วงล่าง
Suspension (ระบบช่วงล่าง) : Full Adjustable Processive coil spring (1 pc) + Oil suspension (2 pcs) (โช้คสปริงแบบปรับระดับได้ 1 ตัว ด้านหลัง + โช้คน้ำมัน 2 ตัว ด้านข้าง)
Wheel size (ขนาดล้อ) : 16 x 3″ (Off-road tyre / ยางแบบออฟโร้ด)
กำลังและแบตเตอรี่
Motor (กำลังมอเตอร์) : 2,500/6,000 watt (PMSM type), 3,000 RPM
Climbing Grade (การไต่ความชัน) : 45°
Battery (แบตเตอรี่) : 60 V 38.5 Ah
Charge time (เวลาชาร์จ) : 2.5-3.5 hrs
คุณสมบัติที่น่าสนใจ
Lighting (ไฟส่องสว่าง) : Adjustable Headlight
Display (จอแสดงผล) : LED display (จอ LED)
Water Resistance (มาตราฐานการกันน้ำ) : IPX6 for wheel, IPX7 for battery (กันน้ำกันฝนกันฝุ่น + ฉีดล้างได้)
Dimension: : 1,890 x 780 x 1,050 mm
Max Load (รับน้ำหนักได้) : 100 kg
คุณสมบัติแบบละเอียด
Motor
Motor Type: PMSM
Weight / Motor External Diameter: 7.0kg / 180mm
Motor Axial Length: 130mm
Peak Efficiency: 95.60%
Cooling Method: Air-Cooled
Controller
Controller Type: X Version Sine Wave
Dimensions: 240mm x 110mm x 50mm
Peak Efficiency: 98.50%
Power Modes: Eco and Sport
MOTOR
Rated Voltage: 60V (DC)
Rated Power / Peak Power: 3,000W / 6,000W
Motor Shaft Output Torque @ 1000RPM: 35.40Nm
Max.torque 8.5 Nm/34 Nm
Rated Rotation Speed: 4300rpm
Peak Efficiency: 97.8%
Range of Efficiency (≥80): 1.4Nm – 21.5Nm
Certificates
Road Legal: No
MOTOR
Gear Ratio: 1:7.6
Transmission: Primary Belt & 420 Drive Chain
Electrical components
ELECTRICAL COMPONENTS
Battery: 60V 32A Lithium Battery with 176 Panasonic Cells
Battery Life: 500 Cycles (reduces thereafter)
Battery Charge Indicator: Integrated LCD Display
Charger: 10A
Charging Time: 2.5-3.5 Hours
USB Connection: Single USB-2.1 A Socket
Speedometer: LCD Digital Speedometer
Headlight & Rear Light: LED
Vehicle
Chassis & Swingarm: Forged Aluminum
Chassis Surface & Colour Processing: Anodic Oxidation
Front Suspension: KKE or DNM, Adjustable for Preload & Rebound
Rear Shock Absorber: KKE or DNM Shock with TR Suspension Link System, Adjustable for Compression & Rebound
Wheel Type & Size: 19 x 1.4 Wire-Spoke Wheels Front/Rear, Alloy Hubs
Tire Size: 70/100-19 Front/Rear
Max Range: 100km @ 32km/h depending upon terrain
Net Weight: 47kg (Plus Battery
Max Load: 100kg (220 lbs.)
Max Climbing Angle: 45 degrees
Rear Sprocket: 48T
Side Stand: With Kill Switch
Vehicle Dimensions: 1,870mm x 780mm x 1,040mm
Minimum Ground Clearance: 270mm
Wheelbase: 1,260mm
Seat Height: 84-88cm
The electric, off-road Light Bee X promises advanced fun on all terrain.
The Light Bee X offers 60V of power from a removable Panasonic lithium ion battery pack. A forged, lightweight aluminum frame, combined with high-spec components, results in a total weight of just 50 kg. 4-piston hydraulic disc brakes are mounted front and rear.The LCD dash is handlebar-mounted, and a convenient USB charger sits right in front of the rider. With a climbing ability of over 45 degrees, up to 100 km of range and a short 2.5-3.5-hour charge time, the Light Bee X offers hours of near-silent fun.
Updates to our 2022 models include:
- New colours (black, blue, silver) and optional graphics
- Sine wave controller for smoother power with more torque, plus ReGen for improved range
- KKE or DNM suspension
- Improved riding position: wider, thicker seat combined with a wider, higher handlebar
- Heavier-duty gold O-ring chain for lower maintenance and reduced noise
- Updated brakes: 4-piston, titanium-finished calipers, now with sintered pads for improved heat dissipation and braking power
- Pro handlebar grips in grey
*Unless otherwise noted, ALL products sold from Sur Ron™ and authorized dealers are sold with the sole intention for off road or race track use only. This product or products may not comply with some State, Federal, Provincial and/or Local laws, ordinances, regulations. The buyer takes full responsibility of the use of these products on their vehicle which may or may not conform to all applicable laws and regulations for on road or highway use.
Ultra Lightweight Frame
The Light Bee’s 7.8 kg frame is constructed of aviation-grade aluminum alloy via a fully automatic welding process that ensures consistency in production.
High Performance Brakes
The braking system features opposed, four-piston hydraulic calipers with metallic brake pads and 203 mm discs for safe and reliable stopping power.
Sporty Performance
In SPORTS mode, the Light Bee X puts out 6 kW of power and 250 Nm of torque. That’s more than enough for tackling jumps and climbing hills!
- 50 kg curb weight
- 100+ km effective cruising range
- Fast charging within 3 hours
- 250 Nm max torque
- Climbing angle of 45 degrees
Great for road and off-road
The Light Bee L1E will ensure a smooth and powerful driving experience on-road and off-road no matter the circumstances. It’s lightweight alloy frame as well as the new and improved controls and the added comfort of rode use mirrors are well-fitted specifically for urban use, meanwhile the vehicles super powerful motor in combination with the twin-tube telescopic shock absorber make it the perfect ride for exploring exciting off-road terrains.
Choose between 2 driving modes
Tired of monotonous driving? The Light Bee L1E comes with 2 diverse driving modes – economical and sport. Choose the economical mode when manoeuvring between the busy city roads and simply switch to sport mode when entering rugged off-road areas. The eco mode supports the average motorcycle speed of 25 km/h. If you wish to add more acceleration and power to your ride, opt for the sport mode (up to 45 km/h). Enjoy your drive whichever way you like it best!
Introducing more power with the ‘’X’’ controller
In case you need any further prompting in purchasing this street-legal super machine, we might add that this model is equipped with a Sin-Wave ‘’X’’ controller that is digitally controlled and programmed to bring even more power and torque to the table. And that’s not all! The ‘’X’’ controller also provides a predictable power curve across the entire operating range. That means smooth and predictable performance anywhere you go.
Equipped with
Removable Panasonic Lithium-ion battery pack, durable and lightweight alloy frame, hydraulic disc brakes, LCD dashboard, dual-LED front and rear lights, 2 x driving modes, 1 x USB charging port, twin-tube telescopic shock absorber, battery level indicator.
